Model: RBC-A (Does not include a motor) / RBC-B (Include a gear box)
JIMWAY’S PATENTED BRUSH BELT CLEANER WITH HUNDREDS OF SBR FINGERTIPS PROVIDES EFFECTIVE CLEANING PERFORMANCE ON DRY FINES CLINGING TO CLEATED BELTS WITH CHEVRONS OR RIBS.
The conveyor belts are kept clean, reduced carryback, which results in lower clean-up costs and less unplanned downtime. In addition, carryback adheres to the belt, which causes serious material accumulation and residue build-up return rollers. Therefore, belt mistracking or belt-edge damage results in unscheduled downtime. JIMWAY’s brush belt cleaners are designed for difficult applications, fines and fibers, including wood dust, cement dust, salt, sugar, fertilizer, and carbon black.
Quick info
| Belt width | 600~2000mm [24″~78″] |
| Belt speed | N/A |
| Cleaning direction | Reversible direction |
| Blade material | SBR |
High abrasion resistance
Effective cleaning without excessive power consumption (RBC-A)
Effective cleaning without power consumption (RBC-B)
| Model | BW | L1 | L2 | Blades Req. |
| RBC-060 | 600 [24] | 530 | 650 | 7 |
| RBC-065 | 650 [26] | 610 | 700 | 8 |
| RBC-075 | 750 [30] | 690 | 800 | 9 |
| RBC-080 | 800 [31] | 760 | 850 | 10 |
| RBC-090 | 900 [36] | 840 | 950 | 11 |
| RBC-100 | 1000 [40] | 920 | 1050 | 12 |
| RBC-105 | 1050 [42] | 990 | 1100 | 13 |
| RBC-120 | 1200 [48] | 1140 | 1250 | 15 |
| RBC-140 | 1400 [54] | 1300 | 1450 | 17 |
| RBC-150 | 1500 [60] | 1450 | 1550 | 19 |
| RBC-160 | 1600 [63] | 1520 | 1650 | 20 |
| RBC-180 | 1800 [72] | 1600 | 1850 | 21 |
| RBC-200 | 2000 [78] | 1830 | 2050 | 24 |
